Combination Electrotherapy - Ultrasound Therapy Machine

Send Inquiry

Request To Call Back

Combination Electrotherapy - Ultrasound Therapy Machine

Name: Combination Electrotherapy - Ultrasound Therapy Machine
Brand: PHYSIO CARE DEVICES
Price: 55000.0 INR
Availability: InStock

Price 55000.0 INR/ Unit

Get a Price/Quote

MOQ : 1 Unit

Combination Electrotherapy - Ultrasound Therapy Machine Specification

Function
Combined Therapy - Ultrasound and Electrical Stimulation

Temperature Range
5C to 40C

Frequency
50/60 Hz

Properties
Portable, Digital Operation, Dual Therapy Modes

Automation Grade
Semi Automatic

Humidity Range
10% - 85% RH

Height
12 cm

Treatment Type
IFT, TENS, MS, Ultrasound

Display Type
Digital

Power
60 W

Shape
Rectangular

Application
Pain Management, Physiotherapy, Muscle Stimulation, Rehabilitation

Suitable For
Clinics, Hospitals, Physiotherapy Centers

Material
ABS Medical Grade Cabinet

Dimension (L*W*H)
35 cm x 30 cm x 12 cm

Accuracy
5%

Use
Electrotherapy and Ultrasound Therapy

Wall Mounted
1 year

Phase
Single Phase

Weight
Approx. 4.5 kg

Color Code
White & Blue Finish

Product Type
Digital Combination Therapy Unit

Display
LED/LCD Digital Display

Power Source
Electric Mains

Voltage
220 - 240 V AC

Indications
Neuromuscular Disorders, Sprains, Tendinitis, Joint Pain, Edema

Ultrasound Pulse/Continuous Modes
Selectable

Electrotherapy Output Channels
2 Independent Channels

Ultrasound Output Power
15 W (max.)

Accessories
Electrodes, Leads, Ultrasound Applicator, Power Cord, Gel

Cooling System
Air cooled

Waveforms Supported
IFT, TENS, MS, Russian, Galvanic, Faradic

Timer Range
0-99 minutes adjustable

Ultrasound Frequency
1 MHz

Safety Features
Overload Protector, Alarms for Faults

Operation Mode
Continuous and Pulse Modes

About Combination Electrotherapy - Ultrasound Therapy Machine

The Combination Electrotherapy with Ultrasound Therapy Machine is an advanced, multi-function physiotherapy device designed to deliver effective pain relief, muscle stimulation, and tissue healing in a single system. It integrates multiple electrotherapy modalities with therapeutic ultrasound, making it ideal for comprehensive rehabilitation and pain management treatments.

This machine supports IFT, TENS, EMS/Muscle Stimulation, and Therapeutic Ultrasound (1 & 3 MHz), allowing clinicians to treat a wide range of acute and chronic musculoskeletal conditions. The digital control panel with preset treatment programs ensures accurate therapy delivery, ease of operation, and consistent results.

Its sturdy trolley-mounted design with multiple output channels enables simultaneous treatment of multiple areas, improving clinic efficiency. The ultrasound function promotes deep tissue healing, increases blood circulation, and reduces inflammation, while electrotherapy modes help relieve pain, reduce muscle spasm, and strengthen muscles.

Versatile Pain Management Solution

An all-encompassing therapy machine, this product supports electrotherapy and ultrasound modalities for diverse medical needs such as muscle stimulation, pain alleviation, and rehabilitation. Its dual therapy modes-electrotherapy and ultrasound-can be used separately or together for tailored treatments. The device's digital controls and adjustable parameters allow precise therapy planning, ensuring convenience and effectiveness in busy clinical environments.

Safety and User-Friendly Operation

Designed with safety as a priority, the machine incorporates an overload protector and fault alarms to keep users and patients secure during treatments. The robust ABS medical grade cabinet, combined with its air-cooling system, further guarantees reliability even with continuous use. Operation is streamlined with a clear LED/LCD digital display and intuitive controls, making the device suitable for clinics, hospitals, and physiotherapy centers.

FAQ's of Combination Electrotherapy - Ultrasound Therapy Machine:

Q: How does the Combination Electrotherapy - Ultrasound Therapy Machine benefit patients with neuromuscular disorders?

A: This machine employs a range of electrical waveforms and ultrasound therapy to alleviate pain, reduce edema, and promote tissue healing in patients suffering from neuromuscular disorders. The dual therapy capability allows practitioners to target both surface and deeper tissue structures for more comprehensive pain management and rehabilitation.

Q: What are the main applications and indications for using this machine?

A: The device is primarily used for pain management, muscle stimulation, physical rehabilitation, and treatment of conditions such as sprains, tendinitis, joint pain, edema, and various neuromuscular disorders. It is suitable for use in clinics, hospitals, and physiotherapy centers.

Q: When should I choose continuous versus pulse ultrasound modes?

A: Continuous mode is best for deep tissue heating and chronic musculoskeletal pain, while pulse mode is typically used for acute conditions or when a gentler, less intense effect is needed. The mode selection depends on your treatment goals and the patient's specific condition.

Q: Where can I operate this electrotherapy and ultrasound therapy machine?

A: This device is designed for professional settings including clinics, hospitals, physiotherapy centers, and rehabilitation facilities. Its compact, wall-mountable design, portable build, and digital controls make it adaptable for a variety of healthcare environments.

Q: What is the procedure for setting up treatment using this machine?

A: To begin therapy, connect the required accessories (electrodes, ultrasound applicator, etc.), select the appropriate waveform or ultrasound mode, and adjust the treatment parameters such as intensity, timer, and mode (continuous or pulse). Ensure proper application of ultrasound gel and secure electrode placement for effective results. Always supervise the session for safety and adjust as necessary.

Q: How do the safety features protect users during operation?

A: The built-in overload protector and fault alarms monitor the machine's operation, shutting down output or providing alerts if abnormal conditions are detected. These features help ensure patient safety and prevent device damage during use.
