ultrasound machine 1 & 3 Mhz

Send Inquiry

Product Code : pcd-108

Brand Name : physio care devices

Price And Quantity

Minimum Order Quantity
1
Unit of Measure
Piece/Pieces

Price
14000 INR

Product Specifications

Portable
Yes
Recyclable
Yes

Recommended For
Nerves, Muscles, Back, Cervical, Joints, Shoulder
Frequency Range
1 & 3 mhz Megahertz (MHZ)

Product Description

Product specification

Micro processor controlled Digital Unit
Pulsed and Continuous therapy operation 10%,20%, 50% and 100%
Variable duty cycle output of 16 Hz, 48 Hz, or100 Hz.
Clinical protocols, the most appropriate application and parameter set for the patients condition.
light weight designs for Clinic, Hospital and Home visits.
Auto detection of Ultrasound applicator.
Micro controller based design for optimum accuracy.
Soft touch buttons.
Timer: 0-30 min
put power is up to 2.5 watts / cm2, which is controlled digitally
back light LCD display

TECHNICAL SPECIFICATION:

Frequency: 1 & 3 MHz
Ultrasound Output: 15 Acoustic
Ultrasound Head : 2.5watts/cm2
Modes: continuous and pulse waves.
Available voltage: 220v

(For USA and Canada buyer, we will provide voltage converter free of cost)

ACCESSORIES:

Main Unit: 01 No.
Ultrasound Applicator: 02 Nos. (1 for 1 Mhz & 1 for 3Mhz)
Power socket /Cord provided for different countries: 01No.
Instruction Manual: 01 No
Carry Bag :01 No.

APPLICATION:

Therapeutic Ultrasound provides therapeutic deep heat treatment for
Relaxation
Reduce swelling and inflammation.
Promote the synthesis of proteins inside the cells
Lymphatic Drainage with cellulite reduction
Regenerate wounded tissues
Accelerate the metabolism of cells

Preset Ultrasound Programmes:

Micro controller based ULTRA-SOUND contains 100programmes, which are divided into following manners:
Prg. 1-32 are set programmes (With all parameter setexcept, Power Level which varies from 0.0 to 2.5W/cm sq )
Prg. 33-80 are Blank programmes. (Company upgradationpro.)
Prg. 80-89 are User defined programmes.

List of Clinical Program

Cervical, Mus. Spam, Acute 3MHz
Cervical, Mus. Spam, Sub acute 3MHz
Cervical, Mus. Spam, Chronic 3MHz
Cervical Mus. Strn., Acute 3MHz
Cervical, Mus. Stm., Sub acute 3MHz
Cervical, Mus. Stm., Chronic 3MHz
Cervical, Nrv. Root IMHz
Thoracic, Mps. Spam, Acute 1MHz
Thoracic, Mus. Spam, Sub acute 1MHz
Thoracic, Mus. Spam, Chronic 1MHz
Thoracic, Mus. Stm., Acute 1MHz
Thoracic, Mus. Stm., Sub acute 1MHz
Thoracic, Mus. Stm., Chronic I MHz
Lumber, Mus. Spam, Acute 1MHz
Lumber, Mus. SpamÃ¢â¬Å¾Sub acute I MHz
Lumber, Mus. Spam, Chronic 1MHz
Lumber, Mus. Stm., Acute I MHz
Lumber, Mus. Stm., Sub acute 1MHz
Lumber, Mus. Stm., Chronic 1MHz
Lumber, Nrv. Root . 1/v1Hz
Shoulder,Bicip Tendon, Acute 1MHz
Shoulder,Bieip Tendon, Sub acute 1MHz
Shoulder,Bicip Tendon, Chronic 1MHz
Shoulder, Bursitis, Acute 1MHz
Shoulder, Bursitis, Sub acute 1MHz
Shoulder, Rot. Cuff Acute 3MHz
Shoulder, Bursitis, Sub acute 1MHz
Shoulder, Rot. Cuff Acute 3MHz
Shoulder, Rot. Cuff, Sub acute 3MHz
Shoulder, Rot. Cuff Chronic 3MHz
Elbow, Olecrunon, Acute 3MHz
Elbow, Olecrunon, Sub acute 3MHz
Elbow, Lateral, Acute 3MHz
Elbow, Lateral, Sub acute 3MHz

INDICATION( Continuous/ Pulsed )

Continuous output is preferable for following indications

Chronic Neuromata

Myalgia

Sudeks syndrome

Tethered scar tissue- This should be treated as early as possible & the increased circulations etc. frees the scars if very localized then it should be pulsed ultrasound.

Pulse output is preferable for following indications.

Severe sprain & strains of muscle fibers, tendons& ligaments-Previously these used to take weeks to get a full functions but with ultrasound now takes days.

Crushed hands or feet- the immediate use of ultrasonic therapy prevents the formation of fibrous tissue, by the absorption the free blood etc, making the early restoration of function possible when the fractureal low.

Dislocation of fractures into or near joints- these tooshould be treated immediately to preventadhesions forming as

the result of unabsorbed free fluids.

Haematoma from severe muscle tears & haemarthrosisfrom trauma or haemophilia the quick absorption of free blood is essential forspeedy restoration of function.

Acute tenosynovitis, tendonitis, de quevain s stenopsingtendo- vaginities etc. quick recovery

Acute synovit is or capsulit is quick recovery

Carpul tunnel syndrome often effective

Reticular nerve pains i.e. Brachial neuritis,inter costalis neuritis lumbago, sciatica etc. pulsed ultrasound given to the appropriate nerve roots gives immediate reduction in pain.

Herpes Zostar- the residual nerve pains is greatly reduced in about 50% of the patients.

Anldyosing spondylitis most effective in early stages,reduces pain & increase mobility. This progressive disease can be kept at a very slow face of progression if repeated courses of treatment are given .

Scar tissue - early treatment prevents keloid scare formation and softness existing new scars.

Neuromata- it is new scar formation This pain will be completely stopped.
